2023 Focus JAM 6.9

Description



  • HYDROFORMING ALUMINIUM FRAME WITH FULLY INTEGRATED C.I.S. CABLE ROUTING AND SMARTLY ATTACHED TOOL BAG
  • 150 MM TRAVEL WITH NEW F.O.L.D. KINEMATICS OPTIMIZED FOR MORE PROGRESSION: FOX 36 PERFORMANCE SUSPENSION FORK AND DPS REAR SHOCK
  • HIGH PRECISION AND EXTREME RELIABILITY: SHIMANO XT 1X12 SHIFTING AND STRONG SHIMANO XT 4-PISTON BRAKES

MAKES THE MOUNTAINS YOUR PLAYGROUND

OPTIMIZED KINEMATICS FOR STRONG PROGRESSION

With the upgrade of our well-known F.O.L.D. kinematics, your JAM is ready to shred even more. We kept the well-liked sensitivity of the F.O.L.D. but changed the positioning of our kinematics within the frame for strong bottom-out resistance. The characteristics are completely progressive which results in a chassis that offers a lot of stability in rough terrain. This allows you to handle any trail while the chassis still provides comfort for long laps. Furthermore, the lower standover of the JAM gives you more space to play on the trail.

FOR YOUR INNER CHILD

The JAM is made for your inner child: Playful and intuitive you get the most fun out of every ride. The geometry is well-balanced for your rides in tough terrain: An agile handling merges with a lot of safety resources of the chassis providing confidence in rough downhills. You are perfectly-seated in the middle of the bike to be in control of any situation and to easily pedal up all the steep hills on your ride. The FLIP CHIP at your linkage can be used to adjust your geometry to an even more aggressive riding style. The small adjustment of the head angle from 65,5° to 65° changes your set-up making it even more downhill-oriented.

INTEGRATED AND CLEAN

It's all about details: The specially developed C.I.S. (Cockpit Integration Solution) design ensures a clean cockpit and constantly seamless shifting and braking. All cables run from the handlebar into the stem and through the headset into the frame. Furthermore, the JAM 6.9 comes with a tool bag between the top and down tube angle. The tool bag offers space for all your essentials like a multi-tool, tube and a small pump.

FRAME 7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. Gen2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 180 mm
FRAME MATERIAL Aluminium
FORK FOX 36 Float Performance 29, Grip 3-Position, 110x15 mm, 44 mm rake
TRAVEL FORK 150 mm
SHOCK FOX Float DPS Performance, 3-position lever, 210/55 mm, hardware: 25,0 x 8mm, custom tune
SHIFTER Shimano Deore XT M8100, 12-speed
REAR DERAILLEUR Shimano Deore XT M8100, 12-speed
SPROCKET Shimano Deore M6100, 12-speed
CHAIN Shimano CN-LG50, 12-speed
CRANKSET Shimano Deore XT FC-M8100, Hollowtech II
BOTTOM BRACKET BSA
TRANSMISSION OF DRIVE Front: 32T, Rear: 11-51T
HANDLEBAR RaceFace Chester 35, aluminium, 780 mm, rise: 35 mm, backsweep: 8°
STEM FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSET ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
SADDLE fi'zi:k Taiga
SEATPOST Post Moderne dropper post PM-171, 31.6 mm
BRAKES Shimano XT M8120, 4 piston
BRAKE LEVER Shimano XT M8120, 4 piston
BRAKE Disc
RIMS RODI TRYP30, 30-622
REAR HUB Novatec D462SB, 12x148 mm
FRONT HUB Novatec D041, 15x110 mm
TIRES Maxxis Minion DHF, 2.5 WT 3C EXO TR, 63-622
REAR TIRE Maxxis Minion DHR II, 2.4 3C EXO+, 60-622
GEARS 12
BIKE WEIGHT 16.15 kg
SIZE S, M, L, XL



* Subject to technical modification without notice. Errors and omissions excepted.

** Weight in size M, of standard specification and without pedals.
