2023 Focus JAM2 SL 9.9 FAZUA 45kph

Description

  • SUPER LIGHT E-MOUNTAIN BIKE THANKS TO A LIGHTWEIGHT MAX CARBON FRAME AND THE FAZUA RIDE 60 E-DRIVE WITH 60 NM AND 430 WH BATTERY
  • 160 MM TRAVEL FOX 36 PERFORMANCE ELITE SUSPENSION FORK AND 150 MM FOX X PERFORMANCE REAR SHOCK WITH F.O.L.D. KINEMATICS
  • HIGH PRECISION AND EXTREME RELIABILITY: SHIMANO XT 1X12 SHIFTING AND XT 4-PISTON BRAKES PLUS FULLY INTEGRATED C.I.S. CABLE ROUTING AND DT SWISS HX1700 LS WHEELS
  • MAXIMUM ASSISTANCE UP TO 45KM/H

MERGES THE BEST OF TWO WORLDS

NIMBLE AND LIGHT PURE BIKE CHARACTERISTICS

With maximum suspension performance, piggy-back shock and super reliable brakes, the JAM² SL 9.9 is all about shredding trails. Thanks to the shock semi-integration, the JAM² SL 9.9 has a low stand-over height that gives you generous space for moving. Still, all parts to adjust your shock settings are easy to reach. As the motor and battery of our JAM² SL 9.9 are fully integrated in the down tube, this e-MTB not just rides but also looks like a pure bike. The MAX carbon layup makes this full-carbon frame super light without compromising on stiffness.

SUPPORT POWER OF AN E-BIKE

The FAZUA Ride 60 drive unit provides the feeling of a natural ride but still has got your back on all climbs. The compact and light, yet powerful system has 60 Nm torque and a maximum power output of 450 W. If you need an extra push, the boost function helps you to tackle even the steepest sections. Thanks to the high efficiency of the FAZUA system and a battery with 430 Wh, your ride won't stop before reaching your very own Rider's High. If you really need even more, adding a range extender offers you further 210 Wh. The drive system already features three different riding modes. On top, you can individualize the motor support based on your riding preferences via the FAZUA App. It allows you to set Max Power, Support Relation and Ramp-up according to your own personal needs.

ADJUSTABLE GEOMETRY AND ADAPTED KINEMATICS

The JAM² SL 9.9 features two points to adjust your geometry: the head angle and the chainstay length. The steeper head angle of 65,5° results in a more agile handling of the bike, while the slack position of 64,5° gives it a more downhill-oriented setting. Switching the FLIP CHIPs and adjusting your chainstay length from 440 to 447 mm changes the whole set-up of your bike. With longer chainstays, the JAM² SL 9.9 rides more stable and makes steep climbs easier, whereas the short setting leads to a more agile geometry. For the JAM² SL 9.9, we adapted our F.O.L.D. (FOCUS Optimised Linkage Design) and reduced the amount of linkage parts resulting in a significant weight loss. The updated kinematic design reduces brake influences and gives you maximum control of your bike in every situation.

FRAME MAX Carbon technologie, 150mm F.O.L.D. GEN3 kinematics, 148x12 thru axle, internal cable routing, Post Mount 180 mm
FORK FOX 36 Float Performance Elite 29, Grip 2, 110 x 15 mm, 44 mm rake
TRAVEL OF SUSPENSION FORK 160 mm
SHOCK FOX Float X Performance, 210/55 mm, hardware: 25,0 x 8.0, no Bushing
MOTOR Fazua Ride 60, 60 Nm, 430 W max.
BATTERY WATT-HOURS 430 Wh
BATTERY AMPERE HOURS 10 Ah
DISPLAY Fazua LED Hub + Ring Control
SHIFTER Shimano Deore XT M8100, 12-speed
REAR DERAILLEUR Shimano Deore XT M8100, 12-speed
SPROCKET Shimano Deore XT M8100, 12-speed
CHAIN Shimano SLX M7100, 12-speed
CRANKSET Rotor eKAPIC RF Link 29
TRANSMISSION OF DRIVE Front: 32T, Rear: 10-51T
BOTTOM BRACKET Integrated in Drive Unit
HANDLEBAR RaceFace Atlas 35, aluminium, 820 mm, rise: 35 mm, backsweep: 8°
STEM FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSET ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated, 1.5/1.5" angle headset
SADDLE fi'zi:k Taiga
SEATPOST Post Moderne dropper post PM-MT171, 31.6 mm
BRAKE CALIPER Shimano XT M8120, 4 piston
BRAKE LEVER Shimano XT M8120, 4 piston
BRAKE Disc
WHEELSET DT Swiss HX1700 LS, 30-622, 110x15 mm / 12x148 mm
FRONT TIRE Schwalbe Magic Mary, 2.4 Super Ground Soft, 62-622
REAR TIRE Schwalbe Nobby Nic 2.4 SuperTrail SpeedGrip
GEARS 12
BIKE WEIGHT INCL. BATTERY IN KG 19.2
SIZE S, M, L, XL



Speed limit for e-support in New Zealand is 45 km/h. Our Fazua Motor and Battery e-bikes are adjusted accordingly.

* Subject to technical modification without notice. Errors and omissions excepted.

** Weight in size M, of standard specification and without pedals.
